Welded Fabric & Mesh Machinery

#666-344  AWM Welded Wire Mesh PlantAWM (Italy) Semi-Automatic Welded Wire Mesh Line; Model Easynet S; max. width: 2400mm, min.-max. wire dia. long + cross: 5 to 12mm, long-cross wire straightened + pre-cut, max # of long. wires: 24, pitch between long + cross wires: 100-150-200mm, 12 x 150KVA transformers, stacker & turner;Fully Automatic Special Welded Wire Mesh Line:max. width: 630mm (24″), min.-max. wire dia. 3-5mm,  cross + long. fed from coil, max. long. wires: 12, (6) six AC 50KVA transformers; supplied new 2007

 #666-379  Pratto Mesh Welder, Model Starweld PE-13-2100; new 2009; for the production of mesh rolls; mesh width: 2100mm; min.-max. wire dia: 1.4-3mm; line wire spacing: min. 25mm; cross wire spacing min. 12.5mm; SPM: up to 160; consisting of: payoff tower frame, entry straightening-propulsion for long. wires, Loop (LAR), wire propulsion-straightening; cross wire uncoiling unit, cross wire loop, auto cross wire with straightening, welding unit, mesh trimming-shear, mesh bending caliber, mesh ejection and stacking unit, mesh turnover, roll take-up; Voltage: 380V-50cycle-3ph

 #666-380  Pratto Mesh Welder, Model Starweld POB-36-2100; production of mesh panels and 3D (bent) mesh panels; mesh width: 2100mm; wire dia. longitudinal + cross wires: 3-6mm; line wire spacing min.: 50mm; cross wire spacing min.: 25mm; SPM: up to 140; 5 x 250 KVA transformers; max. number line wires: 42 @ 50mm wire spacing; max. length of panels: 6000mm (20′); line consists of: payoff system, straightening-propulsion for longitudinal wires, loop (LAR), powered straightening, cross wire payoff unit, cross wire loop, auto cross wire feed, welder, mesh trimming shear, mesh bending press, mesh ejection + staking-turner, exit rolls



#666-384  Schlatter Pg24/38 Mesh Welding Line; max. working width: 2700mm (106″-8’8″); max. welding width: 2450mm (8′); long. + cross wire min.-max. 3.15 to 8.0mm (.125″-.315″); min./max. long. + cross wire spacing: 50mm; welder set up for 14 line wires; 6″x6″ mesh; long. wires fed from coil; cross wire hopper fed; wire straighteners; 6 x 63KVA transformers; 380V-50cy-3ph; guillotine/shear; Schlatter weld controls; spare parts

#666-390  Davis/Robinson style Mesh Welding Line; 8′; Line wire diameter: 10ga (W1.4) to 6ga (W2.9); Cross wire diameter: 10ga (W1.4) to 6ga (W2.9); Line wire spacing: currently fixed 6” across 96”; fully automatic cross wire feed; automatic longitudinal wire feed from coils; fully operational – excellent condition

Mesh welder is no longer available.  Only the coil take-up unit is available.

To view video, click on this link:

  https://youtu.be/sLP2id71-D4

 #666-393  Robinson-Renco Style Reinforcement Mesh Coiler; 8’6″ max. width; 500 lb. weight capacity plus; 200 ft. mesh roll; electrical motor; air pneumatic

 #666-394  Mesh Coiling Machine; heavy duty; ideal for pipe mesh; max. coil weight: 7000 lbs; max. width: 113″; mesh example: max. .400″ wire dia. @ 2″ spacing: 55 line wires; max. coil dia: 76″, min: 36″; (2) collapsible mandrels: (1) 8″ dia. x 9’8″L; (1) 18″ dia. x 9’8″ long; hydraulic power pack; 40 HP GEC motor

 #666-395  Davis style Mesh Coiler; 8′ mandrel; 500 lbs. mesh coil weight; pre-tension roll assembly, motor and controls

 #666-401  EVG Welded Mesh Line; Model G5/102; automatic; wire dia. 4-10mm; max. mesh width: 2500mm; min.-max. welding width: 1800mm min – 2800mm max.; longitudinal pitch spacing: 100-200; traverse/ cross wire: 50-250; 110SPM; longitudinal and cross wire fed from spools; auto cross wire feed; 24 bobbin payoff stand; prestraightening unit; pulling unit; power 800 KVA + 30; 400V-50cycle-3ph

Click here to view video: https://www.youtube.com/watch?v=jRKg6BRxL6w

 #666-403  Pittini-Impianti Wire Mesh Welding Line; max. width: 2500mm (98″; 8′); wire dia: longitudinal & cross wire: 4 to 10mm; max. number of longitudinal wires: 24; longitudinal wire space: 100-200mm; cross wire spacing: 50-250mm; SPM: 130; 12x100KVA transformers; Siemens electricals; line consists of payoffs from coil; LAR feed; 24′ line wire straightening units; welding unit; guillotine/shear; turner & stacker; electrical controls; spare parts

 Ref. #466G-572
Harex Milled Cut Steel Fibers Machines for Concrete Reinforcement
; milled cut fibers made from steel slabs: quality S355. 3 machines: (2) two Harex type FVH130-2, (1) one FW55; width of slabs: 150,200,250,300mm; height of slabs: 450-900mm; length: 7000mm max; (2) slabs same time: 220 x 900 x 7000mm; forms: triangular transversal section; hooked ends; light longitudinal torsion; fiber dimensions: length: 32mm + 2mm, width: 3.80 + 0.50mm; tensile strength: min. 800N/mm2; packaging in boxes: 20-25kg; yearly production: 15,000 ton – Ref. 466G-572 (#659-813, #666-404)

 #666-406  Clifford Model CLW12 Mesh Welder; production of welded basekets, shelving, fencing, reinforcement panels; max. line and cross wire: 8mm (.312″); min. line-cross wire: 2.00mm (.078″); max. cross wire length: 1300mm(51″); max. welding width: 1200mm; cross wire and longitudinal wire pre-cut; cross and longitudinal wire double drop; max. longitudinal length: 100″ (2450mm) (8’3″); long spacing min. 1″ 25mm); edge trimming; coining press and punch; hydraulic unit; 220-480V, 60 cycle; large assortment of parts and tooling

 #666-407  M.E.P. Beta Systems Type MTM400 Lattice Girder Weld Line; lattice girder height: 300mm to 800mm; lattice width: 90 to 110mm; lattice pitch: 200mm; upper and lower wire dia.: min.-max. 5 to 12mm; fret wire (zig zag) min-max.: 3.5 to 6mm; lattice girder length: min.-max. 1600mm to 12,000mm; 883 KVA; 380V-50cycle-3phase; excellent condition

 #666-410  Schlatter MG28 Mesh Welding Line; wire mesh width: 2650mm; line + cross wire dia: 4-10mm; longitudinal wires from straight & cut; cross wire auto feed/cut from coil; line wire spacings: min. 100mm; cross wire spacings 25 to 250mm; max. mesh length: 6000mm, min. 2500mm; line wire feed: LVB1/32; mesh pull-out: ZG28-MAZ4; stacker & turner



#666-413  AWM Lattice Girder/Truss Welding Line; new 2006; dia. wires: upper & lower: 6 to 14mm; dia. of fret/zig-zag wire: 5 to 6mm; pitch/spacing of cross wire: from 190 to 210mm; height of truss: 100 to 300mm; lattice girder pitch: 400mm; length of truss: 2M to 14meters; 35 to 70 cycles/min.; (4) transformers at 315 kVA each; 400V-50Hz

#666-414  SMEI Lattice Girder/Truss Welding Line; min.-max. wire dia. upper & lower wire: 5 to 10mm; max. fret wire: 8mm; min.-max. girder height: 80-320mm; min.-max. base width: 70 to 100mm; min.-max. girder length: 2 to 13.6 meters; gap: 200mm; 70 SPM; new 2004, refurbished 2016, renewed with SIEMENS components PLC; excellent condition

Click here to view videos:
https://www.youtube.com/watch?v=PIMz_whYR5I
https://www.youtube.com/watch?v=CVOMqRe1mEk
https://www.youtube.com/watch?v=nys2Tlgtnpk

#666-415  EVG Model G7 Mesh Welding Line; max. working width: 2700mm; welding width: 2600mm; min.-max. dia: line + cross wires 4 to 12mm; line wire pitch: 100-150-200-300mm; cross wire min.: 50mm; 90 SPM; line + cross wires from pre-cut; mesh pullout-runout

#666-418  EVG Model LGR/52 Wire Mesh Machine; min.-max. wire dia. longitudinal & cross wire: .148″ to .250″ (3.8-6.3mm); max. welding width: 52″; long. wire of coils: cross wire pre-cut hopper fed; min. line wire spacing: 1-1/2″; cross wire spacing: 3/4″ (.750″/19mm); strokes per min: 120 to 130 approx.; (4) 150 kVA transformers; double cut shear; programmable stacker; electrical-weld controls; in process of being rebuilt

#633C-2088
Spool Rack Stand for 38 position, 30mm dia. Pentre spools

#666-420 EVG Lattice Girder Welding Line, Model TS7-25; girder height: 70 to 250mm; upper wire dia: 6-12mm, lower wire dia: 5-12mm; fret- zig-zag wire dia: 4-6mm, zig-zag spacing: 200mm; girder base dimension: 40-60-80mm; 90 SPM; 260KVA; 380V-50 cycle; revamped, running condition

Click here to view video: https://www.youtube.com/watch?v=qC7o_vISSio

#666-421  EVG Model WM3/65 Roll Mesh Take-up; width of fabric: 1700mm(65″); dia. of roll: 1000mm(40″); dia. of roll mandrel: 200mm; roll wire dia: 3-6mm; center height of mandrel: 800mm(31″); tension rollers; hydraulic pump unit; 8KW mandrel motor; operators pulpit; mesh roll discharge; no electrical controls; previously used on EVG GRS65 mesh welder

#666-422  EVG Model G45/102 Welded Wire Mesh Line; max. working width: 2750mm; max. welding width: 2600mm (102″); cross + longitudinal wire dia. range: 3 to 9/10mm; line wire + cross wire from coils (auto cross wire); cross wire spacings: 50 to 400mm steplessly adjustable (2″-16″); line wire spacings: 50 to 300mm; max. welding cap.: 19mm; strokes per min: 75 to 90; 6 x 100 KVA transformers; 380V-3-50cycle power; 100kw power; line consists of: LAR power loop feed, wire tangle unit, line wire straighteners, mesh welder G45/102″ auto cross wire feed, shear, stacker turner, EVG-Lenz electricals

#666-425 (c/r#79A-1750)  ENBOMAK Powder Coating Line: Ideal for wire fence racks, grids; continuous conveyor loop system; 205Mts in length; (5) spray washing cabins/units, 5x15KW pumps; 15Mts drying cabin, infrared; (2) powder coating paint cabins with 12 robotic paint guns for each; 22Mts paining oven, kiln & infrared; all metal parts inner and outer made of 317 stainless steel; system is modular and installed without welding

Click here to view video:
https://www.youtube.com/watch?v=zhG_gDRdGLQ
https://www.youtube.com/watch?v=QVYHJt1Mfsw

#666-426  Schlatter Model MG303 Welded Wire Mesh Line; mesh width: max: 3400mm; min: 1000mm; line wire dia: 4.0-10.0mm; cross wire: 4 to 8/10mm; smooth or ribbed; longitudinal wires; line wire spacing: 100, 150, 200mm, larger in multiples of 50mm; cross wire spacing: min. 50mm; fed from spools/coils: LAR feed: SZ wire; line wire straighteners; welder: MG36.4/17C-E05; transformers: Type C: 17 x 100 KVA; 420V-50cycle

Click here to view video: https://www.youtube.com/watch?v=njQ-jtOzmVw

#666-427  Jager GS930 Mesh Welding Line; max. mesh width: 3400mm; min.-max. line wire from spool: 4mm-10mm; min.-max. cross wire from spool: 4mm-10mm; min.-max. mesh length: 1000mm-6000mm

#666-429  Jager Superflex Mesh Welding Line; max. welding width: 3600mm; min.-max. line wire: 6mm-25mm; min.-max. cross wire: 4mm-16mm; min.-max. mesh length: 1800mm-14000mm

To view videos, click here:
https://www.youtube.com/watch?v=vfCBRBBZS5o
https://www.youtube.com/watch?v=WTNh8sWqxcQ
https://www.youtube.com/watch?v=91itkuhFBtc

#666-430  Schlatter Pg12 Welded Wire Mesh Line; semi-automatic; longitudinal and transversal wire: 4-12mm; 1250mm working width; 1200mm welding width; 1250mm crossbar loader-wire straight & pre-cut wires; 4 transformers at 125 kVA; 5 welding presses

#666-431  EVG HFBE Automatic Mesh Welding Line; max. working width: 4000mm(13ft); length of longitudinal rods: 300-12,000mm; largest mesh: 4000 x 12,000mm, smallest: 500 x 800mm; diameters of longitudinal & cross wires: 6-16mm; longitudinal spacing: 50mm; cross wire: 30mm; supplied with Filzmoser RA-XE-16/6 multiple wire straight & cut; number of wires: 6; wire dia. ranges: 6-16mm; auto rod advance unit to welder; auto mesh take-off/stacker

Click here to view video:
 https://www.youtube.com/watch?v=mJTdtQdesGk

#666-432  EVG Model QC6 Semi-Automatic Mesh Welding Line; max. working width: 3350mm; max. welding width: 3200mm; line wire spacings: 50/75/100/125/150/175; cross wire spacings: min. 50mm steplessly adjustable; line wires dia: 4-16mm; cross wire: 4-12mm(16mm); max. length of mesh: 20,000mm; number of line wires (equipped for 65); number of transformers: 14 x 100KVA; voltage: 380V/50Hz; 14 transformers

#666-433  EVG Model LSM 12/48-8 Mesh Welding Line; max. mesh width: 750mm(30″); min. 200mm (7’8″); line wire from spools: min.-max.: 8mm-12mm; cross wire from spools: 4-5mm (auto cross wire); line wire spacing: min. 100mm, max.: 300mm; mesh length: min.-max. 2000-6000mm; 415V-50 cycle; 8 wire payoff

Ref. #466G-574  Welded Wire Mesh Plant
EVG Mesh Welder
, Model GE 12/102-LTPV, semi-auto., long + cross wires from pre-cut, max. width: 2450mm(8′), min.-max. mesh length: 2000-6000mm (12′-20′), min.-max. cross wire spacing: 50-400mm, long. + cross wire dia.: 4-12mm max., approx. 110 strokes per min.
(2) EVG Wire/Rod Straight & Cut Machines, Models DRE 8-C and DRE 12-C, stationary shears
8-C wire dia. range: 4-8mm
12-C wire dia. range: 6-12mm
spinning arbor/rotor, rotating shear cutoff, speeds: min.-max. 80-160 mts/min., rod collection table: 6 Mts(20′), payoff turntable
Eurodraw Rolling Deformed Line, enter wire dia: 16-5.5mm, outlet wire dia: 14-4mm, speed: 11.0 Mts/sec., rolling mill Model MTO760, (2) two horizontal blocks, block dia: 760mm, 170 KW AC, (2) DEM Rolling Cassettes, Pay Station model SVD/2, (2) hydraulic tilt payoff stands, 2 x 3000 Kg, Mechanical Descaler Model RD140/2, Soap Dispenser-applicator, Spooler – horizontal-traversing Model BOM1250, flange: 1250mm, Siei Sistemi 400V, 3ph, 50Hz, PLC drives Siemens Simatic S7

Click here to view videos:
https://www.youtube.com/watch?v=5SQ8HmuiQ80
https://www.youtube.com/watch?v=j5Z2RdFLRnM
https://www.youtube.com/watch?v=End3QukVLY4

#666-436  EVG Model KFR-804 Mesh Welding Line; max. welding width: 83-1/2″; line wire spacings: min.: 1/4″ up to 2″; cross wire spacing: 1/4″ up to 2″; range wire dia.: 0.5-1.4mm; max. weld capacity: 2.8mm; max. working speed: 160 SPM

#666-438  Welded Wire Mesh Production Plant; Mesh Welding Line Model MG208, min.-max. welding width: 1000 to 2500mm (40″-98.4″); line wire spacing: 75mm-300mm; cross wire spacing: min. 50mm (2″) to 250mm; 32 line wires (set up for 13); cross & line wire dia: 4-8mm; 120 SPM; Koch Model KHB3000 Wire Drawer & Deformer: (2) Rolling Cassettes; WEZ-3 Descaling Unit; BSG/T Dry Coating Units: KHS1250 horizontal spooler; UKA-2 payoff-tower system; (2) Wafios Model R-43 Straight & Cut Machines; (1) 2013, (1) 2007, 3-10mm wire dia.

#666-439  A.W.M. Automatic Mesh Line; Model MR-ST-AA-EA-AA/2,4-6; new 2003; dia. of longitudinal + cross wires: 4-8mm; min.-max. width: 1000-2400mm; min.-max. length: 2000-6000mm; max. number of longitudinal (line) wires: 24; min. distance between longitudinal wires: 100mm; min.-max. distance between cross wires:  50-400mm

#666-440  EVG Wire Mesh Welding Line; Model G45A/102; max. width (cross wire): 2750mm (108″-9ft); cross wire spacings: min.-max.: 50 to 400mm; line wire: 50-75-100-200-250-300mm; cross wire dia. min.-max.: 4-9mm; auto cross wire feed; line wire dia. min.-max.: 3-8mm; line wires fed from coils; speed: 70 SPM; presently set up for 14 line wires.
Line consists of line wire guides, line wire straighteners-DE4/102″, G45A/102 welder, TQ3000V cross wire payoff, HG200H cross wire payoff, AS4/102 interlock device, line wire shear, M4/102 Reinking-Kolbus sheet stacker & turner; nominal power: 380V; main voltage: 415V-50HZ, electrics & controls

(more video links available upon request.)

#666-441  A.W.M. Electroweld Lattice Girder Plant; Model ARM-ST-AA-EA-DX 200/100+250/2+12

#666-442  EVG Model GZF/85-HP; max. working width: 90″(2250mm); max. welding width: 85 (2137mm); min.-max. line & cross wire dia.: 1.0 to 3.0mm, line wire spacing: min. 12.5(1/2″); cross wire spacing: min.: 12.5mm(1/2″); line & cross wires from coils; SPM: 100 max. approx.; payoff back frame; line wire interlock device; line wire break detection; line wire straighteners; mesh torsion; edge trimming & slitting units; cross wire payoff; coil winder for rolls; drive motor: 20 KVA, 380V-50-3ph7

Click here to view videos:

https://www.youtube.com/watch?v=MYbvaln7IiM

https://www.youtube.com/watch?v=MfYfofBMjQQ

https://www.youtube.com/watch?v=oZqHaD2cUBY

https://www.youtube.com/watch?v=8-JQCwthi0k

https://www.youtube.com/watch?v=TH2Kmz6_tEw

https://www.youtube.com/watch?v=x2Sj6OI82kA

https://www.youtube.com/watch?v=ILcHfEnR96A

#666-443  EVG Mesh Welding Line; Model GRS/144-C; presently producing 3D fence mesh; welding width: 3760mm (144″); welding length: max. 3000mm (adjustable); cross wire spacing: min. 0.5″(1/2″, 12.5mm) steplessly adjustable; line wire spacing: min. 1″ (25mm) steplessly adjustable; cross wire dia. min. 2mm (.078″) – max. 6mm (.236″); line wire dia. min. 2mm (.078″), max. 8mm (.318″); speed: 120 SPM – cross wire; payoff turntable; cross wire payoff system; line wire guide/pull unit; line wire straighteners; welder; mesh shear; (2) Japan Robot mesh turner-stacker offline; 12′ press brake; tooled for 3D fence panels; nominal welding transformer power load: 50% of I.D., 1500 KVA; drive motor: 274 KVA; 400V-50 cycle

#666-444 (#32A-161) Machine for production of steel fibers (fully automatic) with hooked ends, closed type, M-1 Model ZSN; 0.8-1.2mm fiber diameter, 50mm fiber length; 15 spools; 11kW enging consumption; includes command and control unit, dust suction, spools platform, spare parts
