Straighteners & Cutoffs

                                                                                           Scroll down page to view all machinery listings…

#627-1024  Mubea Straight & Cut Machine; min.-max. wire dia. 6 to 14mm (.236″ to .551″); flying shear; (5) indexing rotary arbors; (4) pre-feed rolls; 80 to 120 mts/min; max. cutoff lgth: 14 meter track; indexing wire/rod collector; 30kW (40HP) AC motor; hydraulic motor: 15 kW (20HP); operators control panel; 380V- 50 cycle – 3ph; (4) vertical payoff units

#627-1026  KRB Model 1016 Straight & Cut Machine; 10 to 16mm (#3-#5 rebar) has cut 6.3mm; 360 FPM; variable speed; twin straightening rotors; hydraulic flying shears; pre-feed rolls; 40′ runout track; 30HP straightening motors; 20HP hydraulic pack; operators computer console; new 2007; excellent condition

Click here to view video:
https://www.youtube.com/watch?v=Rqo9cAfeN7Y

#627-1032  Lewis Model 6C Straight & Cut Machine; wire dia. cap. min-max .156″-.312″ (3.9-8.0mm); 3′ runout track; 15 HP motor; 5 die rotary arbor; stationary cam cutoff

SOLD – NO LONGER AVAILABLE     #627-1044  Lewis Model 8-F Travel-Cut Straight & Cut Machine; wire dia. cap: .156″-.375″; 5/32″-3/8″ (4.0 to 9.5mm); feed speeds: 110-125-135-160-200 FPM; 20′ runout track; min. cutting length: 11″; 25HP; 600V motor; feed rolls air pneumatic – SOLD – NO LONGER AVAILABLE

#627-1056  Lewis Model 11-12FHA Straight & Cut Machine; wire/rod min.-max. straightening: 3/8″ to 3/4″; cutting capacity over 3/4″ for higher tensile rod; 20′ travel cutoff; flying shear; pneumatic feed roll pressure; cutoff shear; air clutch; 100HP main drive; Astec model PO-3/4″1-FD Powered Payoff

#627-1061  Lubow Straight & Cut Machine, model Lorex 8; wire dia. range: .125″-.312″ (3.17-8mm); 10′ runout track; stationary cutoff; 7.5kW (10HP) arbor motor; 2.2kW (6HP) feed & shear motor; misc. tooling

#627-1062  Lubow Straight & Cut Machine, Model Lorex 12;  wire dia. range: .125″ to .375″ (3.17 to 9mm); 16’5″(198″) runout track; stationary cutoff; 12.5kW arbor motor; 4Kw feed cutoff motor; misc. tooling; Cutler Hammer controls

#627-1067  Shuster 2A4V Straight & Cut Machine; min.-max. wire dia: .125 to .312″ (3.1-8.0mm); 10′ runout track; low-medium carbon wire; stationary cut-off; 200 FPM; 4-roll feed rolls; 10HP DC; Reeves Vari-drive

Click here to view video: https://youtu.be/33oTtSh_sC4

#627-1057  Eurobend Model MELC16x2PLC Multi-Line Straight and Cut Machine; new 2009; 2 wire line; 8 to 16mm (5/16″-5/8″); 20′ runout; flying shear; 300 FPM; Hyperbolic straightening and feeding system; PLC numerical control system; 2 payoff units

Click here to view videos:

#627-1074  Shuster Model 2A4V Straight & Cut Machine; min.-max. wire dia. .125″-.312″ (3.1-8.0mm); 10′ runout track; low-medium carbon; stationary cutoff; 200 FPM; 4 feed rolls; 10 HP DC; Reeves vari drive

#627-1083  Lewis Model 10F Wire Straight & Cut Machine; wire dia. range: 3/8″ to 5/8″ basic steel: 1/2″ high carbon; speeds: 90-115-130-165 FPM; runout track: 25 feet; flying shear; pneumatic wire-rod compactor; Durapulse electrics; tooling for 5/16″- 3/8″- 11/32″ -13/32″ -7/16″ -5/8″; dual turntable payoffs: 64″ dia. tables

#627-1084  Wafios RBK51-M Straight & Cut Machine; wire dia. range: 3.0-14.0mm smooth wire (900N/mm2): 6.0 to 12.00mm high carbon-ribbed (900N/mm2); 130M/min.; runout track: 45 feet; rotary arbor with 5 dies; rotating shear cutoff; motor power: 37KW 380V-50cycle (50HP); shear motor: 7.5KW (10HP); shortest cut: 12″; dual turntable payoffs: 64″ dia.; Tecvil electrical panel with Siemens drive

#627-1085  Wafios RBK51-MB Straight & Cut Machine; wire dia. range: 8.0-14.0mm smooth wire (900N/mm2): 6.0 to 12.00mm high carbon-ribbed (900N/mm2); 130M/min.; runout track: 24 feet; rotary arbor with 5 dies; rotating shear cutoff; motor power: 37KW 380V-50cycle (50HP); shear motor: 7.5KW (10HP); shortest cut: 12″; dual turntable payoffs: 64″ dia.; Tecvil electrical panel with Siemens drive
