Hexagonal Netting Machinery

#162-177   Hexagonal Wire Netting Machine; 4 meter wide; wire dia. range: 2.0mm-4.2mm; mesh size 80mm to 100mm; 32 strokes/min.; spiral coiling spring making machine; wire tensioning device; payoff from spools

#162-188  Wafios Model HD Hexagonal Netting Weaving Machine; mesh size: 51mm; wire dia range: 1.00mm; max mesh width: 3300mm; 80 SPM; payoff; roll take-up; voltage: 380V-3ph-50cycle

#162-198  Wafios Model SF-21 Hexagonal Netting Machine; standard twist; wire dia. min.-max.: 0.6-1.1mm(.023″-.043″); mesh size: 3/4″ (can do 1-1/2″ by skipping 1 hole); max. netting width: 6’11” (2.1 M); number of strokes/min: 125; BM-4 Spiral Coiling Machine; (1) Spooling machine for steel spools

Click here to view video:

#162-200  Wafios Model SF-23 Hexagonal Netting Machines; standard twist; 2 available: (1) 1″ spacing, (1) 1/2″ spacing; maximum weaving width: 2200mm (86″); wire diameters: min. 0.06mm-0.90mm (.023″-.035″); max. 2.2mm (.089″); drive motor: 5.5kw; 50-90 SPM; each weaver supplied with DW5S spiral spooler; 380V-50 cycle

#162-204  Hexagonal Wire Netting Machine; standard twist; ideal for gabion products; 4 meter wide; wire dia. range: 2.0-4.2mm approx.; last weaving: 2.6-3.4mm; mesh size: 80mm x 100mm; 32 SPM; powered roll take-up; floor mounted wire guides; 4 wire spiral coiling machine; 44M/min

#162-205  Wafios Model HD33 x 50mm x 1mm Hexagonal Netting Machine; reverse twist with spoolers; max. mesh: 50mm; mfg. in 1960, upgraded in 1999; 57 beats per min.
